Eahora P5 24-Inch Fat-Tire Electric Bike
Every Redtail e-bike includes a free 1-month warranty plus manufacturer coverage. Add the Redtail Care Package for dedicated support from our US-based team — remote diagnostics, manufacturer claim handling & return-shipping coordination — for up to 5 years.
Your selected plan is added automatically when you tap Add to Cart. No Care Package is added by default.
A support & service plan — it does not cover physical repairs or replacement parts. See full Care Package details →
The same magnesium-framed 24-inch cruiser Eahora also sells as the P5 Plus — for three hundred dollars more.
The P5 is Eahora's 24-inch fat-tire cruiser: a 750W geared hub with 85 N·m, a 960Wh 48V 20Ah pack that accepts a second 15Ah battery, a magnesium-alloy frame and full suspension, at 84.8 lb. Before you order, read the ledger: Eahora also lists a 'P5 Plus' at $999 whose published specification is identical to this one, row for row. Its brakes are mechanical rather than hydraulic, and it was not buyable on 2026-08-24.
- 750WGeared hub, 85 N·m
- 960Wh48V 20Ah, expandable
- 24" × 4.0"Fat tires
- 84.8 lbCurb weight
- MagnesiumAlloy frame
Who the P5 is for
Buy it if
- Riders who want the magnesium-framed 24-inch platform and are buying this listing specifically
- Anyone who may want more range later — Eahora states the pack accepts an additional 15Ah battery
- Riders who want a 24-inch wheel: more rollover than a 20, lower and more manoeuvrable than a 26
- Buyers who want a stated class on the page: this is one of four Eahora models that publishes one
Or one of these instead
- You are buying on specifications alone — Eahora's own P5 Plus publishes an identical sheet for $999
- You want hydraulic brakes: Eahora specifies mechanical disc brakes on this model
- You need it now — the single listed configuration was not buyable on 2026-08-24
Magnesium alloy, not steel
A magnesium-alloy frame in a 24" × 18" size — the only frame material in Eahora's catalog that is not high-carbon steel. Magnesium is lighter for the same stiffness and does not rust, which is a real advantage on a bike that lives outside or sees winter roads.
960 watt-hours, expandable to 35Ah
A 48V 20Ah pack with, in Eahora's words, an extra 15Ah battery available to add. That takes the bike to roughly 1,680Wh if you want it later. Publishing an expansion path at all is unusual; what Eahora does not publish is the mounting, the price, or how the two packs are switched.
Twenty-four inch fat tires
24" × 4.0" tires on 36-hole, 12-gauge aluminum spoked rims — a middle wheel size between Eahora's 20-inch commuters and its 26-inch Romeos, and the only bikes in the range on 24s apart from the P5 II.
Adjustable at the rear
A 100mm mechanical suspension alloy fork and a 500mm adjustable rear shock. Rear adjustment matters more than usual here, because a second battery is a meaningful weight change over the back wheel.
Named Shimano parts
A TY300 shifter, an M315 derailleur and an MF-TZ500-7 14–28T freewheel on a 44T crank, with a T50 rust-resistant chain of 126 links. Model numbers throughout, which is what makes a drivetrain serviceable rather than disposable.
The honest ledger
Green flags
- 48V × 20Ah = 960Wh, exactly as printed, and all 25 watt-hour claims across Eahora's catalog recompute correctly
- A magnesium-alloy frame — lighter than steel and rust-immune, where every other bike in this catalog is high-carbon steel
- An expandable battery: Eahora states an extra 15Ah pack can be added, taking it to roughly 1,680Wh
- Electronics and drivetrain named to the part number — YL91F-H display, Shimano TY300, M315, MF-TZ500-7
- Eahora publishes "24 - 27 MPH for PAS & throttle" for this model
Red flags
- Eahora's own 'P5 Plus' listing publishes an IDENTICAL specification — all 35 spec rows and 9 geometry rows — for $999, three hundred dollars less. The SKUs differ; nothing published does
- Mechanical, not hydraulic, disc brakes — more hand force, more fade on descents, and periodic cable adjustment
- No powered tail light, only a reflector, and no fenders
- The 24-to-27 mph band Eahora quotes covers pedal assist and throttle alike. A throttle is capped at 20 mph in many states, so that is the half of the band worth checking against your own rule
Speed and the law — read this before you buy
This is one of only four Eahora models that states a class on its own page: its spec row reads 'Class 3 ebike with 5-level pedal assist and throttle.' Two things are worth knowing before you rely on it. First, Eahora quotes a 24-to-27 mph band covering pedal assist and throttle, rather than the single top-speed row, so the 28 mph pedal-assist ceiling that defines Class 3 has only that band to be read against. Second, in many states Class 3 is defined as pedal-assist only, with throttle assistance capped at 20 mph separately; a bike offering both to the same ceiling may not meet that definition where you live. A class is a conclusion under your state's statute rather than a manufacturer's label, so read your own state's rule in Redtail's law guide, and ask us if it is not clear.
Speed figure as published by Eahora on this model's own page, archived 2026-08-24. Class definitions and the rules that follow from them are state law, not manufacturer copy — check yours in Redtail's state-by-state e-bike law guide before you ride. Not sure how it applies where you live? Email support@redtailebikes.com and we will read the statute with you.
How the P5 compares
All figures are Eahora's own published specifications, read from each model's archived product page on 2026-08-24.
| Spec | P5 | P5 Plus | P5 II | FT-01 Max |
|---|---|---|---|---|
| Price | $1,299 | $999 | $1,599 | $1,799 |
| Motor | 750 W DC geared hub, cassette drive | 750 W DC geared hub, cassette drive | 1,500 W DC hub motor, cassette drive | 1,500 W DC hub motor, cassette drive |
| Battery | 960 Wh (48V 20Ah); Eahora states an extra 15Ah pack can be added | 960 Wh (48V 20Ah); Eahora states an extra 15Ah pack can be added | 960 Wh (48V 20Ah); Eahora states an extra 15Ah pack can be added | 1,440 Wh (48V 30Ah) |
| Top speed (Eahora) | 24–27 mph, quoted by Eahora as one band for pedal assist and throttle | 24–27 mph, quoted by Eahora as one band for pedal assist and throttle | 28–34 mph, quoted by Eahora as one band for pedal assist and throttle | 25–28 mph, quoted by Eahora as one band for pedal assist and throttle |
| Range with PAS | 68–80 miles in PAS mode, or 34–40 miles on throttle (manufacturer claim) | 68–80 miles in PAS mode, or 34–40 miles on throttle (manufacturer claim) | 68–80 miles in PAS mode, or 34–40 miles on throttle (manufacturer claim) | 43 miles in PAS mode, or 28 miles on throttle (manufacturer claim) |
| Max load | Rider weight within 330 lb (Eahora's wording) | Rider weight within 330 lb (Eahora's wording) | Rider weight within 330 lb (Eahora's wording) | Rider weight within 330 lb (Eahora's wording) |
| Brakes | 180mm front and rear MECHANICAL disc brakes — not hydraulic | 180mm front and rear MECHANICAL disc brakes — not hydraulic | 203mm front and rear hydraulic disc brakes (Eahora's wording: 'oil brakes') | 180mm front and rear hydraulic disc brakes |
| Weight | 84.8 lb in total with the battery; the battery alone is 27.6 lb | 84.8 lb in total with the battery; the battery alone is 27.6 lb | 84.8 lb in total with the battery; the battery alone is 27.6 lb | 90.6 lb in total with the battery; the battery weighs 13.1 lb |
Source: each model's own page on www.eahoraebike.com, archived 2026-08-24. — = not published by Eahora for that model.
Full specifications
| General information | |
|---|---|
| Bike class | Eahora states: 'Class 3 ebike with 5-level pedal assist and throttle' — see the speed-and-law section |
| Top speed | 24–27 mph, quoted by Eahora as one band for pedal assist and throttle |
| Range per charge | 68–80 miles in PAS mode, or 34–40 miles on throttle (manufacturer claim) |
| Max load | Rider weight within 330 lb (Eahora's wording) |
| Rider height | 5'5" – 6'1" (165–185 cm) |
| Bike weight | 84.8 lb in total with the battery; the battery alone is 27.6 lb |
| Ideal use | IP65 waterproof — motor, battery, display and wiring |
| Power | |
| Battery | 960 Wh (48V 20Ah); Eahora states an extra 15Ah pack can be added |
| Battery lifespan | Not published for this model |
| Motor power | 750 W DC geared hub, cassette drive |
| Motor torque | 85 N·m rated |
| Motor type | DC geared hub motor |
| PAS levels | 5 levels |
| Throttle | Thumb throttle |
| Controller | 48V, 25 ± 1A, 12 MOSFET |
| Display | 4" portrait color display (YL91F-H), 100 cd/m² brightness |
| Drivetrain | Shimano 7-speed — TY300 shifter, M315 derailleur, MF-TZ500-7 14–28T freewheel |
| Charger | 54.6V 3A smart charger, 100–240V input, 6–8 h charge time |
| Wiring | Harness with water-resistant connectors |
| Safety | |
| Brake system | 180mm front and rear MECHANICAL disc brakes — not hydraulic (see notes) |
| Brake levers | Aluminum alloy with motor cutoff switch |
| Frame | Magnesium alloy, 24" × 18" |
| Front fork | 100mm travel mechanical suspension alloy fork |
| Rear shock | 500mm adjustable shock absorber |
| Headlight | 48V 20W LED |
| Tail light | Rear reflector only — no powered tail light |
| Tires | 24" × 4.0"; pressure marked on the sidewall |
| Saddle | Leather fabric, breathable, memory foam |
| Handlebar | Rise, 720mm × 22.2mm |
| Components | |
| Crankset | 44T × 170mm, single-sided chainring guard |
| Chain | T50 alloy steel rust-resistant, 126 links |
| Pedals | 9/16", polymer bearing |
| Rims | Aluminum spoke, 24" × 4" × 12G × 36H |
| Seatpost | Aluminum with clamp |
| Kickstand | Aluminum alloy with plastic foot |
| Fenders | None |
| Rack | Optional |
| Bell | Finger-dial, right side |
Specifications as published by Eahora at www.eahoraebike.com/products/eahora-p5se, archived 2026-08-24, and reproduced in Eahora's own groupings. These are the manufacturer's ratings, not Redtail test results. Found an error? Email support@redtailebikes.com.
Size and fit
Eahora publishes a geometry block for this bike, and one row needs flagging: the rim-diameter figure is a 20-inch-bike number appearing on a 24-inch bike. Everything below is as published, with that problem marked.
| Measurement | Eahora’s figure |
|---|---|
| Recommended rider height | 5'5" – 6'1" (165–185 cm) |
| Total length | 72.8" (185 cm) |
| Wheelbase | 46.6" (118 cm) |
| Seat height | 35" – 38.9" (89–99 cm), adjustable |
| Handlebar height | 42" (107 cm) |
| Rim diameter | published as 16.4" (42 cm) — which cannot be right on a bike specified with 24" × 4.0" tires; do not buy parts against this row |
| Standover | 23.6" (60 cm) |
| Reach | 15.75" (40 cm) |
| Chainstay length | 20.5" (52 cm) |
Geometry as published in the Size & Geometry block on www.eahoraebike.com/products/eahora-p5se, archived 2026-08-24. Between two sizes, or right at the edge of the height range? Email support@redtailebikes.com with your inseam before you order.
How to read this spec sheet
Manufacturer pages contain marketing, and marketing sometimes disagrees with the spec table an inch below it. Rather than quietly pick numbers, here is every place Eahora's own material disagrees with itself for this model, and which figure we print:
- Eahora lists two P5s with IDENTICAL published specifications and different prices: 'P5 Plus' at $999 (SKU PX1002) and 'P5' at $1,299 (SKU PX1001). We compared all 35 specification rows and all 9 geometry rows on 2026-08-24 and not one value differs — same 750W motor, same 85 N·m, same 960Wh pack, same mechanical brakes, same frame, same weight. The SKUs differ, so they are distinct items in Eahora's own system, but nothing it publishes distinguishes them. We report the comparison rather than resolve it, and we will put the question to Eahora in writing if you want the answer before ordering.
- Brakes are MECHANICAL disc brakes — Eahora's own row reads '180MM front and rear mechanic disc brakes'. These and the P5 Plus are the only cable-actuated brakes in Eahora's current catalog.
- The geometry block gives 'Rim Diameter 16.4" or 42CM' while the tire row specifies 24" × 4.0". A 24-inch tire does not mount on a 16.4-inch rim; this is the figure Eahora uses on its 20-inch bikes appearing on a 24-inch one. Buy tires, tubes and rims against the 24" × 4.0" specification, not the geometry row.
- Eahora quotes a 24-to-27 mph band covering pedal assist and throttle, in place of a single top-speed row.
- Battery: 48V × 20Ah = 960Wh, matching Eahora's printed figure. The arithmetic is ours.
- Availability: the single listed configuration read unavailable on both Eahora endpoints on 2026-08-24.
- Warranty: Eahora's coverage table (published only as an image) gives 24 months on the frame; the same page states a one-year claims deadline. Both are Eahora's; we print both.
Warranty
| Component | Coverage |
|---|---|
| Frame | 24 months — covers desoldering and material fracture |
| Fork | 12 months — performance failure |
| Motor | 12 months — quality fault, break down, or performance failure |
| Battery | 12 months — quality fault, or measured capacity below 50% of rated capacity (the battery housing is excluded) |
| Controller | 6 months — performance failure |
| Charger | 3 months — performance failure |
| Display / dashboard | 3 months — performance failure |
| Tires | 3 months — cracking or leaking |
| Saddle | 3 months — cracking or damage |
| Front / middle axle | 3 months — performance failure |
| All other parts | 3 months — damage or performance |
What it covers
Manufacturing defects under normal use, for the original owner, on the components and for the periods in the table above. Eahora's stated remedy is free replacement parts shipped within the continental U.S.; only bikes it judges unrepairable (its example is a severely broken frame) go back for inspection, and Eahora provides the label in that case.
What you must do
- Proof of purchase from Redtail (your order confirmation is enough)
- Photos or video of the fault with any claim — Eahora requires both before it reviews
- Report shipping damage within 10 days of delivery on Eahora's terms, and within 48 hours on ours — so work to the 48-hour window and you are inside both
- Use Eahora-approved parts and chargers; its warranty excludes damage caused by anything else
Not covered
- Normal wear and tear — tires, brake pads, chains and other consumables (Eahora's own wording)
- Damage from misuse, accidents, modifications, improper maintenance, or non-original parts
- Water damage, extreme weather, and force-majeure events
- Second-hand owners and commercial use
- Damage from crashes, overloading, stunts, or unauthorized repairs
- The battery housing (the cells and their measured capacity are covered; the case is not)
- A second motor replacement — Eahora charges for replacement and freight once a motor has already been replaced under warranty
- Eahora's warranty page sets a 24-month frame period in its coverage table, then closes with 'Claims deadline: 1 year from purchase date.' The two statements are on the same page and are not reconciled anywhere on it. We print both and treat 12 months as the figure to plan around; if you need the frame claim in year two, tell us and we will put it to Eahora in writing before you order.
- Eahora's own storefront header advertises '1 Year Warranty', which matches the claims deadline rather than the 24-month frame row.
Eahora Limited Warranty issued by Eahora, as published on its warranty page — where the coverage table is posted as an image rather than as text, so every row above was read off that image on 2026-08-24 and kept on file. Send photos or video of the issue with your order number and we take it from there — Redtail files and manages the claim with Eahora on your behalf.
Shipping, returns & support
Shipping
Free shipping on every electric bike within the contiguous United States (lower 48).
Orders are prepared and dispatched within 1–3 business days of confirmation. Most e-bikes arrive within 5–10 business days after dispatch, depending on location.
Ships via trusted parcel and freight carriers — UPS, FedEx, and LTL freight for larger items — with tracking emailed at dispatch. For freight, the carrier may call to schedule and a signature may be required.
On delivery
Inspect your shipment at delivery. Damage, defects, or incorrect items must be reported with photos within 48 hours; claims submitted after this window are not accepted.
Bikes with power, charging, or component issues are covered under the manufacturer warranty; Redtail coordinates repair or replacement remotely at no cost to the customer.
Returns
Change-of-mind returns accepted only on unopened, factory-sealed items requested within 72 hours (3 days) of delivery, with a 15% restocking fee plus return shipping. Once a box is opened or a bike is ridden, it is no longer eligible.
Once an eligible return arrives we take up to 5 business days to inspect it; approved refunds issue within 14 days of completed inspection, and your bank may take a further 2–15 business days to post it.
Order cancellations carry a 3% transaction fee, because card-processing fees are non-recoverable.
Alaska, Hawaii, U.S. territories, P.O. boxes, and remote areas may incur extra charges or be excluded — contact us before ordering. Full terms: Redtail Shipping Policy · Redtail Refund & Return Policy. Eahora publishes its own shipping and return terms, which govern orders placed directly with Eahora — not orders placed here. Buying from Redtail means Redtail's terms apply and Redtail handles the manufacturer relationship on your behalf.
Frequently asked questions
Should I buy this or the P5 Plus at $999?
On published specifications there is no reason to pay the difference, and we would rather tell you that than sell you the dearer one. We compared both pages on 2026-08-24: all 35 specification rows and all 9 geometry rows are identical — same motor, torque, battery, frame, brakes, wheels and weight. Their SKUs differ (PX1001 here, PX1002 there), so Eahora treats them as distinct items, but nothing it publishes explains the $300. Ask us and we will put the question to Eahora in writing before you order either.
Are the brakes really mechanical?
Yes. Eahora's row reads '180MM front and rear mechanic disc brakes' — cable-actuated, not hydraulic. That means more hand force at the lever, more fade on a long descent, and periodic adjustment as the cable stretches, though motor cutoff is still fitted to both levers. The P5 II uses hydraulic brakes for $300 more than this listing.
How fast does it go?
Eahora gives 24 to 27 mph as a single band for pedal assist and throttle together, not as one top-speed number, and its spec sheet reads 'Class 3 ebike with 5-level pedal assist and throttle'. Class 3 turns on a 28 mph pedal-assist ceiling, and a throttle is capped at 20 mph in many states. If the number matters for your state, ask us and we will get it from Eahora in writing before you order.
What does the expandable battery actually involve?
Eahora states the 48V 20Ah pack is 'available to add an extra 15Ah battery', taking the bike to 35Ah. What it does not publish is where the second pack mounts, what it costs, or whether the packs run in parallel or switch over. If the upgrade path is why you are buying, let us get those answers from Eahora first — a published sentence is not a fitting guide.
Can I buy it right now?
Not on the evidence we have — the single listed configuration read unavailable on both Eahora endpoints we checked on 2026-08-24. Email support@redtailebikes.com and we will ask Eahora when it is due and pass on exactly what they say.
Is the battery UL certified?
Eahora states that its batteries are 'fully compliant with the rigorous UL certification standards'. It does not name a standard number or a testing laboratory for this model, so if your building, landlord or insurer asks for a certificate document, ask us before you order and we will request it from Eahora in writing.
What warranty applies, and who handles a claim?
Eahora's published terms: 24 months on the frame, 12 on the fork, motor and battery, 6 on the controller, 3 on the charger, display, tires, saddle and other parts. Its page also states a one-year claims deadline, which is the figure to plan around. Claims on a bike bought here run through Redtail — send photos or video with your order number to support@redtailebikes.com and we deal with Eahora. Inspect the box within 48 hours of delivery.
Keep looking
Every Eahora at Redtail · Compare the P5 Plus · Compare the P5 II · Compare the FT-01 Max · E-bike laws in your state · Shop electric bikes by type
Primary sources
- Eahora product page: Eahora P5 24-Inch Fat-Tire Electric Bike www.eahoraebike.com/products/eahora-p5se. Retrieved 2026-08-24.
- Eahora Warranty page www.eahoraebike.com/pages/warranty. Retrieved 2026-08-24.
- Eahora FAQ page www.eahoraebike.com/pages/faq. Retrieved 2026-08-24.
- Eahora Shipping Policy www.eahoraebike.com/pages/shipping-policy. Retrieved 2026-08-24.
- Eahora Refund Policy www.eahoraebike.com/policies/refund-policy. Retrieved 2026-08-24.
- Redtail Shipping Policy. Retrieved 2026-08-24.
- Redtail Refund & Return Policy. Retrieved 2026-08-24.
- Redtail's state-by-state e-bike law guide. Retrieved 2026-08-24.
Specifications and prices are Eahora's own, reproduced as published from the archived copy of its product page, with contradictions in its material flagged rather than resolved silently. Warranty terms are Eahora's; shipping and return terms on this page are Redtail's. Manufacturer sources are cited by name and address rather than linked, because every link on this page should keep you here. Want to see any source we used? Email support@redtailebikes.com and we'll send it.
How we verified this page. Every specification above was read from an archived copy of Eahora's own product page (www.eahoraebike.com/products/eahora-p5se), retrieved 2026-08-24, with the price and every colorway's availability cross-checked the same day against two independent Eahora endpoints. Watt-hour figures were recomputed from the published volts and amp-hours rather than taken on trust. Figures are the manufacturer's ratings, not our test results; where Eahora's material disagrees with itself, the "How to read this spec sheet" section names each conflict and the figure we chose. Prices are USD, matched to Eahora's own store, current at the date shown. Corrections: support@redtailebikes.com.
